Deep Hole Boring Machine 1MAI MGA250X10000

Deep Hole Boring Machine 1MAI MGA250X10000

Contact us for price

Bucharest, Romania

orCall +4 021 223 03 45

Description

Deep Hole Boring Machine 1MAI MGA250X10000 Made in Romania Main technical data: Up to 10 meters boring depth From 60-150mm dia. borin in solid Up to 250mm enlarging an existing hole. - Max. slide. over the guideways 900mm - the maximum diameter of the clamping flange: 500mm - speed domain: 150 - 1100rpm - main motor Siemens 37KW DC - work feed: 0-2400mm / min - rapid feed: 2400mm / min - height of the center axis over the guideways 450mm - max. weight of the work piece 5000kg - width of the bed 550mm - length of the machine 21160mm - machine weight ab. 40ton Accesories: - Steady rests; - Support - other accesories

Specifications

Manufacturer1 MAI
ModelMGA 250X10000
Year1982
ConditionUsed
