2015 Knuth CNC Floor-Type Horizontal Boring Mill Drillmaster 4016

2015 Knuth CNC Floor-Type Horizontal Boring Mill Drillmaster 4016

Contact us for price

Romania

orCall +4 021 223 03 45

Description

Knuth CNC Floor-Type Horizontal Boring Mill Drillmaster 4016 Complex drilling jobs - performed efficiently and with high precision using graphic displays • Rigid weldment with torsion-free gap bridge, and high-precision linear guides on X and Y axis • Hydraulic clamping lever for secure fixation of workpieces • Powerful servo-motors generate dynamic gantry feeds • Z axis with 350 mm travel allows maximum utilization of the entire workspace Specifications working area travel X-axis 1600 mm travel Y-axis 4000 mm travel Z-axis 350 mm table dimensions 1600x4000 mm drilling capacity 50 mm workpiece weight (max.) 3500 kg tool weight max. 5 kg spindle nose-to-table surface distance 446 mm headstock Drehzahlbereich, stufenlos 55 - 570 rpm spindle mount MK 4 feed rapid feed X-axis 12000 mm/min rapid feed Y-axis 12000 mm/min rapid feed Z-axis 12000 mm/min feed speed X-axis 0 - 12000 mm/min feed speed Y-axis 0 - 12000 mm/min feed speed Z-axis 0 - 12000 mm/min drive capacity motor rating main drive 5,5 kW motor rating X-axis 1 kW motor rating Y 2x2 kW motor rating Z 1 kW measures and weights overall dimensions 4300x2100x2000 mm weight 7000 kg For more information please contact us.

Specifications

ManufacturerKnuth CNC Floor-Type Horizontal Boring Mill Drillmaster 4016
Year2015
ConditionUsed
